    Chinese Engine Turning Brake Lathe Machine of 750mm length Metal Price

    Ask Lasest Price
    Brand Name : wadJay
    Model Number : CA-6140
    Certification : ISO 9001
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 100 sets / month
    Delivery Time : 15 working days
    • Product Details
    • Company Profile

    Chinese Engine Turning Brake Lathe Machine of 750mm length Metal Price


    Chinese Engine Turning Brake Lathe Machine of 750mm length Metal Price


    Chinese Engine Turning Brake Lathe Machine of 750mm length Metal Price


    Product Description:

    This lathes can be used for a variety of turning work, such as turning inside and outside cylindrical surface, conical surface, and other turning surface, face, but also processing a variety of commonly used threads - such as metric, inch, modulus, diameter thread, , Hinge, tapping, tipping trunking and so on.

    Machine Features:

    Machine round car specimen, the roundness error is not greater than 0.01mm (the maximum diameter of the bed is greater than 800 when the 0.02), cylindrical error in the 300mm measurement length of not more than 0.04mm. High torsion-resistant flat bed, high-quality cast iron carefully manufactured, and induction on the rail surface quenching precision treatment, bed width 550mm; by the sticky PTFE conductive rails composed of flexible rails wear, vibration, precision retention Good; spindle with three support structure, high rigidity, high precision, can be strong cutting. Spindle through the hole for the 100mm large hole; 18 wide speed range, you can choose a more reasonable speed; can be directly turning metric and inch thread; slide box has a fast moving body.



    Chinese Engine Turning Brake Lathe Machine of 750mm length Metal Price


    SpecificationsCA6140 CA6140BCA6240 CA6240B
    Max. Swing over bed400mm
    Max. Swing over carriage210mm
    Max. swing in gap--630mm
    Effective gap length--210mm
    Max. length of work piece750mm/1000mm/1500mm/2000mm/2200mm/3000mm/4000mm
    Width of bed400mm
    Section of turning tool25x25mm
    SpindleSpindle speeds10-1400rpm/16-1400rpm(24steps)
    Hole through spindle52mm. (80mm)
    Spindle taperNO.6(Φ90 1:20)
    FeedNumber of feeds64 kinds(for each)
    Range of metric threads(kinds)(1-192mm)44kinds
    Range of inch threads(kinds)(2-24tpi)21kinds
    Range of module threads(kinds)0.25-48 (Moduie39kinds)
    Range of pitch threads(kinds)1-96DP(37kinds)
    TailstockMax. tail stock spindle travel150mm
    Tail stock spindle diameter75mm
    Taper of tail stock spindle center holeNO.5
    Main motor7.5KW(10HP)
    Packing dimensions (L*W*Hmm)Overall dimensions for750mm2550x1140x1750
    Overall dimensions for1000mm2700x1140x1750
    Overall dimensions for1500mm3200x1140x1750
    Overall dimensions for2000mm3700x1140x1750
    Overall dimensions for2200mm4030x1140x1750
    Overall dimensions for3000mm4850x1140x1750
    Overall dimensions for4000mm5800x1140x1750
    Weight (kg)LengthG.W N.W.
    Weight for 750mm2100 1990
    Weight for 1000mm2190 2070
    Weight for 1500mm2350 2220
    Weight for 2000mm2720 2570
    Weight for 2200mm2800 2600
    Weight for 3000mm3300 3200
    Weight for 4000mm3500 3400

    Chinese Engine Turning Brake Lathe Machine of 750mm length Metal Price




    Chinese Engine Turning Brake Lathe Machine of 750mm length Metal Price


    Q1. How to send my enquiry?
    You can contact us by email, phone call, message (Whats APP, We Chat, Skype).


    Q2. How long can I get feedback after enquiry?
    We will reply you within 3 hours in working day.


    Q3. Delivery time
    Machines order takes 30 days after deposit payment received. Please inquiry sales.


    Q4. What is the package? Is it suitable for shipment?
    Machine is by waterproof cloth to covered. And be packed by standard exported wooden case with steel foot. It is very much strong for oversea transportation.


    Q5. Payment term
    30% T/T as down payment, balance 70% by T/T before delivery. If others payment terms, we can discuss the details. Welcome to inquiry sales.


    Q6. Can I trust you?
    Sure, we're Made in China Gold Suppliers,
