    3 Axis CK6140 CNC Lathe Machine 808D Controller Tool As Hub Shaping


    3 Axis CK6140 CNC Lathe Machine 808D Controller Tool Used as Hub Shaping


    1- Longitudinal and cross feeds are effected by ball leadscrews driven by servo motors.

    2- Either vertical 4-station or horizontal 6 and 8-station tool post as well as gang type tool post can be selected.The post is located on precision contrite gears with a high repeated positioning accuracy.

    3- Both chuck and tailstock are available with hydraulic or manual or pneumatic type.

    4- The spindle system is high in rigidity and accuracy.

    5- The surface of the bedways is supersonic frequency hardened and precision ground with a long service life.


    Product Parameters


    CNC Lathe Machine CK6140A

    ITM
    CK6140
    CK6150A
    CK6150T
    Max. swing dia. over bed
    400mm
    500mm
    500mm
    Max. swing dia. over cross slide
    245mm
    280mm
    290mm
    Max. workpiece length
    750/1000 mm
    750/1000/1500mm
    750/1000mm
    Width of the bed
    330 mm
    400 mm
    360mm
    Diameter of spindle bore
    Φ60mm
    Φ82mm
    Φ70mm
    Spindle taper
    MT6
    1:20/ Φ90
    1:20/ Φ90
    Spindle nose
    A2-6
    Type of spindle head D-8
    Type of spindle head D-8
    Spindle speed
    200~2500rpm
    150~2500rpm
    150-2000 rpm
    Chuck size
    250mm
    250mm
    250mm
    Tool holder
    4 station
    4 station
    4 station
    Tool bar section
    25x25mm
    25x25mm
    25x25 mm
    Main motor power
    5.5 kw
    7.5 kw
    7.5 kw
    X/Z axis position accuracy
    0.02/0.025mm
    0.02/0.025mm
    0.02/0.025mm
    X/Z axis repeatability
    0.01/0.012mm
    0.01/0.012mm
    0.01/0.012mm
    X/Z axis torque
    5/7.5N.m
    6/10 N.M
    6/10N.m
    X/Z axis fast feeding speed
    6/8M/MIN
    8 /10M/MIN
    8/10M/MIN
    Tailstock sleeve travel
    120mm
    150mm
    150mm
    Tailstock taper
    MT4
    MT5
    MT5
    Dimension
    2320/2570*1400*1700mm
    2410/2660/3160*1560*1730mm
    2660/2910*1560*1730
    Weight
    1800/2000KG
    2800/3200/3500KG
    2500/2800kg

    Standard Configuration

    1- System:GSK928TD-L, servo motor and drive.

    2- Manual 3-jaw chuck.

    3- 4-station electric tool post.

    4- Manual tailstock

    5- Cooling system.

    6- Lighten system.

    7- Automatic lubrication system.
